The Clamping Cylinder and Piston Rod Assembly is a critical component in heavy-duty railway maintenance machinery—serving as the "muscle" that secures rails during tasks like stretching, tamping, or grinding. Built for high strength, precision, and durability, this assembly addresses a key pain point in railway maintenance: the need to hold rails firmly without causing deformation, even under extreme tension. Its core advantages include exceptional clamping force (up to 100kN), precise movement control, and resistance to wear and corrosion. For railway operators, these benefits translate to shorter track occupancy time (faster clamping = faster maintenance) and lower long-term costs (reduced replacement frequency and minimal rail damage).
• High-Strength Material Construction: The cylinder body is made of seamless steel pipe (Q345R grade) for high pressure resistance, while the piston rod uses chrome-plated alloy steel (45# steel) to prevent rust and wear. This combination ensures the assembly can withstand continuous use in harsh railway environments.
• Precision Hydraulic Control: The assembly integrates a pressure relief valve and flow control valve, allowing operators to adjust clamping force and piston speed (0.5–2mm/s) based on rail type. This precision prevents over-clamping (which damages rails) or under-clamping (which risks slippage during maintenance).
• Sealed & Leak-Proof Design: Equipped with imported polyurethane seals (from brands like Parker), the assembly eliminates hydraulic fluid leaks—even under high pressure (up to 31.5MPa). This reduces maintenance work and ensures consistent performance.
• Easy Installation & Replacement: The assembly features a flange-mounted design with standardized bolt holes, making it compatible with most maintenance machinery (e.g., rail stretching machines, tamping machines). Replacement takes less than 2 hours, minimizing downtime.
What is the maximum clamping force of this assembly?
The standard model delivers a maximum clamping force of 100kN, which is sufficient for most rail types (50kg/m to 75kg/m). For heavy-duty applications (e.g., 100kg/m rails used in mining railways), we offer a high-force version with 150kN clamping force.
How do I maintain the clamping cylinder to prevent leaks?
Routine maintenance includes: (1) Checking hydraulic fluid levels and replacing fluid every 6 months (use ISO VG 46 hydraulic oil); (2) Inspecting seals for cracks or wear every 500 hours of operation; (3) Cleaning the piston rod with a lint-free cloth after use to remove dust or debris. Following these steps will prevent 90% of leak issues.
Is the assembly compatible with both 24V and 380V hydraulic systems?
Yes. The assembly’s hydraulic valve block is designed to work with both low-voltage (24V, for mobile machinery) and high-voltage (380V, for fixed machinery) hydraulic power units. We provide a wiring diagram to ensure easy integration with your existing system.
| |
